srp_Hash() returning different output than expected

AusMarkB

As part of implementing oauth, I have to hash and encode a random string of characters which are later verified by the third party.
I'm receiving an error

Transformed code verifier does not match code challenge

which basically means when I pass the string and they hash/encode it, it doesn't match the encoded version I sent previously.

I was thinking I was somehow sending the wrong thing, but after testing using Postman, it appears that srp_hash is providing a subtly different output to their version.

I'm calling srp_hash using these parameters codeChallenge = SRP_Hash(theCode, 'SHA-256', 'BASE64')

For example, this string

czskhjhwhonrgvamtk8224474843883642743586266462367

is returned from srp_hash as

fjZ+3wGKt75TgQTB9tYlxn62rZjlnZ/mLmbwBmua/As

Utillising an online code generator, the same string is returned as

fjZ-3wGKt75TgQTB9tYlxn62rZjlnZ_mLmbwBmua_As

In case it's not obvious, "+" is replaced with "-" and "/" is replaced with "_".

The requirements are specified as

The “code challenge” is created by performing a SHA256 hash on the code verifier and then Base64url encoding the hash

The online tool for performing the hash that returns a value that works can be found here pkce-generator/

Is there anything obvious I've overlooked?

Hold that thought!
As I finished typing, I noticed the "Base64URL" and googled the differences.
I can make the appropriate changes now, but I'll leave this here in case someone else can learn from my ignorance.
And I guess it's worth asking, does srp_hash have an undocumented Base64URL option?

KevinFournier

Not undocumented. Says here that URL and BASE64URL options were added in version 2.1.5.

KevinFournier

Hold that thought!
I haven't had my morning coffee. You said SRP_Hash, not SRP_Encode. Correct, we forgot to update the documentation on that page. But anything supported by SRP_Encode is supported in the the Encode parameter. I updated that page. Sorry for the confusion.

AusMarkB

AusMarkB

Now that I've made an effort to understand what I'm talking about, just thought it might be worth bringing to your attention that Base64URL only seems to be switching the 62nd character "+" and leaving 63 "/".

Also, is there a way to tell it to omit the padding? I see that srp_encode() can omit crlf$ which almost does the job but not quite.
As before, I can handle this all myself now, but it would be nice if the one call, (to srp_encode() at least), did the complete job.

Feel free to slap me if I'm just missing something in my reading/understanding.

KevinFournier

Naw, you're not missing anything. The Encode parameter is the same as calling SRP_Encode with defaults. In fact, that is exactly what SRP_Hash is doing... calling SRP_Encode. So, if you need more control, omit the Encode parameter and call SRP_Encode directly.
